Voltage rating - volts

1,000

Temperature rating °C

-55 to 200

Insulation

Extruded PTFE, wall thickness .015 (.38 mm).

Conductor

Silver-Plated Copper

Conductor Size (AWG)

26

Conductor Diameter - inches (mm)

.019 (.48)

Stranding

19/38

Insulation Diameter Minimum - inches (mm)

.045 (1.14)

Insulation Diameter Maximum - inches (mm)

.053 (1.35)

Weight - pounds/1000 feet (Kg/1000m)

2.48 (3.69)

Maximum Resistance Ohm/1,000 feet (ohm/Km), @ 20°C

38.4 (126)

Options

Nickel-plated copper conductor; silver or nickel-plated high-strength copper alloy conductor; sodium napthalene etched insulation bondability. Also available to NEMA HP-3-EEX.
