Voltage rating - volts

250

Temperature rating °C

-55 to 200

Insulation

Extruded PTFE, wall thickness .006 (.15 mm)

Conductor

Silver-Plated Copper

Conductor Size (AWG)

28

Conductor Diameter - inches (mm)

.015 (.38)

Stranding

7/36

Insulation Diameter Minimum - inches (mm)

.025 (.64)

Insulation Diameter Maximum - inches (mm)

.029 (.74)

Weight - pounds/1000 feet (Kg/1000m)

.910 (1.35)

Maximum Resistance Ohm/1,000 feet (ohm/Km), @ 20°C

63.8 (209)

Options

Nickel-plated copper conductor; silver or nickel-plated high-strength copper alloy conductor; sodium napthalene etched insulation bondability. Also available to NEMA HP-3-ETX.
